The 1.2TL, Project Monolith

Options
1…678911

Comments

  • xschop
    xschop Posts: 5,897
    edited September 29
    Options
    Updated the design to omit one of the pointed detents. This will let the other end self-align perpendicular while pressure is increased. Will make install a breeze....

    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    Options
    Hey Sean, version 2 can be accomplished by machining the large bolt head flat. A 9/16-18 bolt head would have same contact area as 1" round dowel....


    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • ptrooper
    ptrooper Posts: 800
    Options
    Nice work Rob B) . I'll get that measurement soon ,What materials will you use and which glue do you recommend?
    VR3 SDA SRS 1.2TL Duelund Monoliths+VR31000va Dreadnaught +VR3 MM2 SDA cable, <3 ,Lumin u2x ,<-sfp fibre <-LHYas8 Pro+ Switch,Transparent Reference MM2 xlr,power and speaker cables.FTA Sinope SE usb.40 Amp power line for amp with earth stake&Faraday shield ,20 Amp power line for digital equipment ->shunyata 8 venom power board...Working on it!
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    edited October 1
    Options
    Plan on using 7075 alloy and Grade 8 zinc plated bolts and nyloc nuts with copper anti-sieze.
    you'll just need a 13/16" (21mm for you Blokes) wrench to install after a good dab of Loctite Powergrab or Liquid Nails.

    A spring-loaded punch will make for pinpoint placement accuracy as well.
    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • ptrooper
    ptrooper Posts: 800
    edited October 5
    Options
    xschop wrote: »
    Im looking into using 1.25-1.5 Dia. Black Delrin too for damping and resonant characteristics vs. sand filled alloy.

    You given up on this idea Xschop?

    Sinope SE usb Hitting 200 hours, wowza ,I wouldn't recommend using bypass caps!......Upwards and onwards.
    VR3 SDA SRS 1.2TL Duelund Monoliths+VR31000va Dreadnaught +VR3 MM2 SDA cable, <3 ,Lumin u2x ,<-sfp fibre <-LHYas8 Pro+ Switch,Transparent Reference MM2 xlr,power and speaker cables.FTA Sinope SE usb.40 Amp power line for amp with earth stake&Faraday shield ,20 Amp power line for digital equipment ->shunyata 8 venom power board...Working on it!
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    Options
    The point would be pointless as it wouldn't penetrate the particle board under compression. Would be a smudgey affair I'm afraid.

    Think I'll go the extra trouble to butyl wrap the alloy rods just for good measure. B)
    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • ptrooper
    ptrooper Posts: 800
    edited October 8
    Options
    @xscop Hey Rob. How much thread are you planning to be visualised when they’r locked in place ?

    Today the Monoliths play another Aussie Classic. the song that turned my hometown pub , The Morley Generator into a bar fight 875 people with a head full piss(alcohol). The memories. o:) The Angels !,,,,,,Take a long line. A story of individual defiance and alienation when faced with systematic oppression and abuse of power.
    https://www.youtube.com/watch?v=MoYWhzuyNPQ
    Pump it up
    VR3 SDA SRS 1.2TL Duelund Monoliths+VR31000va Dreadnaught +VR3 MM2 SDA cable, <3 ,Lumin u2x ,<-sfp fibre <-LHYas8 Pro+ Switch,Transparent Reference MM2 xlr,power and speaker cables.FTA Sinope SE usb.40 Amp power line for amp with earth stake&Faraday shield ,20 Amp power line for digital equipment ->shunyata 8 venom power board...Working on it!
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    edited October 8
    Options
    Rebellion to tyrants is obedience to God.
    From the bloke on my hunnerds.

    @ 1/2" or less when installed. Why I need a good measurement from you.

    Looking back, I remember an old thread/post that stated there was a thicker front baffle between later and earlier 1.2's.

    I'm going to build a set for my XS-8TLs too.
    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    edited October 9
    Options
    Started prototypes. Still waiting on new tap and nylocs....





    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    edited October 9
    Options
    Shop neighbors are the best...



    Now just waiting on some locknuts from Fastenal...


    When all said and done, hex heads are still 0.950 apex to apex....





    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • skipshot12
    skipshot12 Posts: 2,167
    Options
    How will you be attaching it to the inside, pressure?
    Would putting some type of rubber damping material on the ends help with the cabinet resonance?
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    edited October 9
    Options
    Yes, pressure set by hand-twist of the dowel. These will attach with PowerGrab or Liquid Nails once set just like a wooden dowel, but be simple to install and remove. I plan on pinpointing this set right between top MW and tweeter on the 8TLs as it is the weak spot from factory.

    I just tested the dimple in a piece of plywood. Too easy and won't budge laterally without glue. The old particle board will provide a little more resistance before bottoming out at interface.
    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • ptrooper
    ptrooper Posts: 800
    edited October 10
    Options
    Excellent 😎 this will lock that tweeter array in solid as a rock ,10 in each enclosure ?
    Neutral pressure will be my goal !
    Tuned to 17 Hz
    VR3 SDA SRS 1.2TL Duelund Monoliths+VR31000va Dreadnaught +VR3 MM2 SDA cable, <3 ,Lumin u2x ,<-sfp fibre <-LHYas8 Pro+ Switch,Transparent Reference MM2 xlr,power and speaker cables.FTA Sinope SE usb.40 Amp power line for amp with earth stake&Faraday shield ,20 Amp power line for digital equipment ->shunyata 8 venom power board...Working on it!
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    Options
    That looks like all the weak points are addressed given the orientation of the semi-rings. B)
    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • ptrooper
    ptrooper Posts: 800
    Options
    This was the local 💦 watering hole!
    AC⚡️DC.
    VR3 SDA SRS 1.2TL Duelund Monoliths+VR31000va Dreadnaught +VR3 MM2 SDA cable, <3 ,Lumin u2x ,<-sfp fibre <-LHYas8 Pro+ Switch,Transparent Reference MM2 xlr,power and speaker cables.FTA Sinope SE usb.40 Amp power line for amp with earth stake&Faraday shield ,20 Amp power line for digital equipment ->shunyata 8 venom power board...Working on it!
    · Share on Facebook
  • ptrooper
    ptrooper Posts: 800
    edited October 12
    Options
    xschop wrote: »
    Shop neighbors are the best...



    Now just waiting on some locknuts from Fastenal...


    When all said and done, hex heads are still 0.950 apex to apex....





    When I receive these ,I will wait for the xover plates and tweeter bezzle upgrades before I install them!

    This Sinope cable is in a completely different ball park at 275 hours ,Absolute mesmerising with the depth and detail,I can't wait to get the cabinet vibrations sorted.I listened to a full Sinope cable system ,total cost, 1.2 mill ,OMG ,Could be bye bye to transparent!

    Your 1 Semi ring ,I find do allot more than the other thinner full rings in my SDA SRS ! They actually rung until I glued them along the edges.
    In future ,do you think you could make at least 2 semi rings to interlock as installed per WM? The thicker material definitely shifts any vibrations to a much lower frequency!

    Here's 1 pic ,<3

    Big thanks again to Xschop and Vr3 ,I highly recommend their upgrades!
    VR3 SDA SRS 1.2TL Duelund Monoliths+VR31000va Dreadnaught +VR3 MM2 SDA cable, <3 ,Lumin u2x ,<-sfp fibre <-LHYas8 Pro+ Switch,Transparent Reference MM2 xlr,power and speaker cables.FTA Sinope SE usb.40 Amp power line for amp with earth stake&Faraday shield ,20 Amp power line for digital equipment ->shunyata 8 venom power board...Working on it!
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    edited October 13
    Options
    Final testing. Temp. Installed one in the 8TL right between top MW and tweeter. Point facing forward, adjustable bolt in rear, it self aligns perpendicular EASILY with a simple twist of the rod holding the hex steady. Main design goal achieved. I Rasped on it before and after. Even with only a 9" wide baffle, it stiffened right up and sounds much more inert.

    I still haven't received the locknuts, but once location is decided, all would be needed is Blue Loctite and the PowerGrab/Liq. Nails...


    They are almost dead silent without butyl wrap. Even when I hit them with a metal punch, they have a short clink, but no ringing.

    With butyl wrap....Dead silent....

    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • ptrooper
    ptrooper Posts: 800
    Options
    I will probable wrap these in dynomat etc when they arrive down under, that will save some coinage/postage weight etc.
    one layer on the top dowel and add more to the braces the closer they get to the PR thus making sure not all dowels resonate to the same frequencies.OVERKILL or not?Exciting stuff <3
    VR3 SDA SRS 1.2TL Duelund Monoliths+VR31000va Dreadnaught +VR3 MM2 SDA cable, <3 ,Lumin u2x ,<-sfp fibre <-LHYas8 Pro+ Switch,Transparent Reference MM2 xlr,power and speaker cables.FTA Sinope SE usb.40 Amp power line for amp with earth stake&Faraday shield ,20 Amp power line for digital equipment ->shunyata 8 venom power board...Working on it!
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    Options
    Not so sure that'd be necessary. Even with ear up to them, they are silent when rung.

    When you get me that final dimension, I'm curious what the front baffle thickness is also on the Monoliths, 3/4" or 1" ?
    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
  • ptrooper
    ptrooper Posts: 800
    Options
    Malang to bandung ,I'll be infront of those puppies again soon!

    I don't want these braces all marching to the same tune! Extra dynamat is simple .Adding this progressive mass loading should transform how the cabinet handles energy.

    a rough estimate has me thinking ~560 Hz. is where these rods might tend to get excited.

    By scattering the resonant frequencies across a broad spectrum instead of letting them pile up at 560 Hz, you gain two massive sonic advantages

    • Eliminates Midrange Smearing: The 500 Hz to 600 Hz range is where human hearing is most sensitive to vocals and acoustic details. Stripping out the synchronized rod vibrations ensures that the cabinet stays dead silent, preventing
    forwardness in your midrange.

    • Tighter, Cleaner Infrasonic Bass: With the cabinet completely locked down against baffle-flex , the air pressure generated by 12–15 Hz notes is focused entirely on driving the active mid-bass array and the 15-inch passive radiator rather than shaking the cabinet walls. The bass becomes faster, harder hitting, and completely effortless.

    I'll break up the harmonic chain by altering the weight of the rods from top to bottom. This splits a single 560 Hz resonant spike into a broad, harmless 61 Hz wide spectrum (503 Hz to 564 Hz).

    I was thinking.

    • Top Zone (Dowel 1 at top; Dowels 2 & 3 at top sides of tweeter array) Leave Dowel 1 bare aluminium with a 50mm center collar. Apply 1 single layer of Dynamat to Dowels 2 and 3.

    • Resonance: 531 Hz – 564 Hz
    • Mid Zone (Dowels 4 & 5 at mid-sides; Dowels 6 & 7 at lower-sides of array) Apply 1 full layer plus a 50mm centre collar to 4 and 5. Apply a 1.5-layer spiral wrap to 6 and 7.

    • Resonance: ~516 Hz
    • Bottom Zone (Dowel 8 below tweeter array; Dowels 9 & 10 above passive radiator) Apply 2 full layers to Dowel 8. Apply 2 full layers plus a thick 75mm center collar to 9 and 10.

    Let me know if I'm overthinking it?

    Right now ,I believe Monday to be the measuring day.



    VR3 SDA SRS 1.2TL Duelund Monoliths+VR31000va Dreadnaught +VR3 MM2 SDA cable, <3 ,Lumin u2x ,<-sfp fibre <-LHYas8 Pro+ Switch,Transparent Reference MM2 xlr,power and speaker cables.FTA Sinope SE usb.40 Amp power line for amp with earth stake&Faraday shield ,20 Amp power line for digital equipment ->shunyata 8 venom power board...Working on it!
    · Share on Facebook
  • xschop
    xschop Posts: 5,897
    edited October 16
    Options
    Sounds like a plan. I remembered GM added a bell weight to the C5 Vette torque tube to stop it from ringing but it is hollow and 6 Ft long. Dropped right in the 928 with a carriage and custom axles.
    FYI... C=πD but I had to add extra quarter inch length to the butyl mat when I rolled it on due to the dual layers. Easy Peasy.

    Have a good trip and let us known how the local beer is. B)
    Don't take experimental gene therapies from known eugenicists.
    · Share on Facebook
