SDA 2.3 No bass

124

Comments

  • halo71
    halo71 Posts: 4,602
    Tony, aren't you glad I told you about those 2.3's in Dawsonville? lol
    --Gary--
    Onkyo Integra M504, Bottlehead Foreplay III, Denon SACD, Thiel CS2.3, NHT VT-2, VT-3 and Evolution T6, Infinity RSIIIa, SDA1C and a few dozen other speakers around the house I change in and out.
    · Share on FacebookShare on Twitter
  • tragusa3
    tragusa3 Posts: 48
    vulcan wrote: »
    The DCR readings can be obtained more easily from the terminal cup.
    Use red and black speaker binding posts. The interconnect(IC) cable points are blade is pin#1 and the pin is pin#2

    I did redo the reading from the terminal cup. They changed from my first readings and matched up to the handbook.
    SDASRS2.3, SDA1C, Monitor 10, Monitor 7b
    Klipschorns, LaScalas, Heresy
    JBL8330a
    Infinity Kappa6
    Danley DTS10
    · Share on FacebookShare on Twitter
  • tragusa3
    tragusa3 Posts: 48
    halo71 wrote: »
    Tony, aren't you glad I told you about those 2.3's in Dawsonville? lol

    Gary, are you being sarcastic? I knew what I might be getting into, and I certainly stepped into a project. I'm thankful for you, but not glad yet. It's all part of the journey. :smile:
    SDASRS2.3, SDA1C, Monitor 10, Monitor 7b
    Klipschorns, LaScalas, Heresy
    JBL8330a
    Infinity Kappa6
    Danley DTS10
    · Share on FacebookShare on Twitter
  • xschop
    xschop Posts: 5,000
    pitdogg2 wrote: »
    2.3tl and 2.3 are completely different critters.

    Until someone actually posts the true schematic for MW's between original 2.3 and 2.3TL, then it's all speculation why the drastic re-design. I speculate that the 6511's suck as stereo drivers and Polk re-designed the stereo and SDA circuits in the 2.3TL's for the tighter 6510's.
    Don't take experimental gene therapies from known eugenicists.
    · Share on FacebookShare on Twitter
  • VR3
    VR3 Posts: 28,610
    The 2.3 has sub bass drivers and the 2.3tl does not

    2.3
    - Not Tom ::::::: Any system can play Diana Krall. Only the best can play Limp Bizkit.
    · Share on FacebookShare on Twitter
  • VR3
    VR3 Posts: 28,610
    2.3tl
    - Not Tom ::::::: Any system can play Diana Krall. Only the best can play Limp Bizkit.
    · Share on FacebookShare on Twitter
  • Gardenstater
    Gardenstater Posts: 4,455
    edited July 11
    Not 2 *dedicated* sub-bass drivers in the 2.3tl like in the 2.3. They instead have the dimensional drivers trying to do double duty as SDA dimensionals and also sub-bass stereo drivers.

    And also they swapped sides so that there is a 4 driver stereo line array on the inside and 2 dimensional (plus sub bass stereo) drivers on the outside.

    2.3 has 4 driver array on outside (2 purely dimensionals and 2 purely stereo sub bass) and 2 stereo drivers are on the inside.

    If this is wrong feel free to correct (without unnecessary ridicule).
    George / NJ

    Polk 7B main speakers, std. mods+ (1979, orig owner)
    Martin Logan Dynamo sub w/6ft 14awg Power Cord
    Onkyo A-8017 integrated
    Logitech Squeezebox Touch Streamer w/EDO applet
    iFi nano iDSD DAC
    iPurifier3
    iDefender w/ iPower PS
    Custom Steve Wilson 1m UPOCC Interconnect
    iFi Mercury 0.5m OFHC continuous cast copper USB cable
    Custom Ribbon Speaker Cables, 5ft long, 4N Copper, 14awg, ultra low inductance
    Custom Vibration Isolation Speaker Stands and Sub Platform
    · Share on FacebookShare on Twitter
  • xschop
    xschop Posts: 5,000
    Understand, but how are they SUPPOSED to be wired? A true schematic is in order here, not speculation.
    Don't take experimental gene therapies from known eugenicists.
    · Share on FacebookShare on Twitter
  • tragusa3
    tragusa3 Posts: 48
    edited July 11
    xschop wrote: »
    Understand, but how are they SUPPOSED to be wired? A true schematic is in order here, not speculation.

    George, that is my understanding too. If we had a member with the same speaker that was performing correctly, they could verify wiring for us.
    SDASRS2.3, SDA1C, Monitor 10, Monitor 7b
    Klipschorns, LaScalas, Heresy
    JBL8330a
    Infinity Kappa6
    Danley DTS10
    · Share on FacebookShare on Twitter
  • VR3
    VR3 Posts: 28,610
    - Not Tom ::::::: Any system can play Diana Krall. Only the best can play Limp Bizkit.
    · Share on FacebookShare on Twitter
  • Gardenstater
    Gardenstater Posts: 4,455
    tragusa3 wrote: »
    xschop wrote: »
    Understand, but how are they SUPPOSED to be wired? A true schematic is in order here, not speculation.

    George, that is my understanding too. If we had a member with the same speaker that was performing correctly, they could verify wiring for us.

    Rob (xschop) 👍 That makes 3 of us in agreement 😁👀
    George / NJ

    Polk 7B main speakers, std. mods+ (1979, orig owner)
    Martin Logan Dynamo sub w/6ft 14awg Power Cord
    Onkyo A-8017 integrated
    Logitech Squeezebox Touch Streamer w/EDO applet
    iFi nano iDSD DAC
    iPurifier3
    iDefender w/ iPower PS
    Custom Steve Wilson 1m UPOCC Interconnect
    iFi Mercury 0.5m OFHC continuous cast copper USB cable
    Custom Ribbon Speaker Cables, 5ft long, 4N Copper, 14awg, ultra low inductance
    Custom Vibration Isolation Speaker Stands and Sub Platform
    · Share on FacebookShare on Twitter
  • tragusa3
    tragusa3 Posts: 48
    I may have just found the issue...stay tuned.
    SDASRS2.3, SDA1C, Monitor 10, Monitor 7b
    Klipschorns, LaScalas, Heresy
    JBL8330a
    Infinity Kappa6
    Danley DTS10
    · Share on FacebookShare on Twitter
  • xschop
    xschop Posts: 5,000
    You mean you didn't just throw some more expensive caps in as a hail mary fix-all lol?
    Don't take experimental gene therapies from known eugenicists.
    · Share on FacebookShare on Twitter
  • tragusa3
    tragusa3 Posts: 48
    When putting the drivers back in, I noticed a stray blue that had fallen out of its fast-on. Repaired it...no change. I probably knocked it loose in all my working? Dang it. I was happy for a moment.

    The donut drivers (6513) or sub bass drivers are not putting out the level of sound that the stereo drivers do. Got to be something bad in whatever is sending sound to those. Like I originally stated, they are playing, but roughly 50% of the excursion and volume of the others. I did test every driver with a 9v battery and they all moved with the same exact excursion. I wonder if I can find which frequencies are sent to the donuts? If it coincides with the sudden drop my SPL meter shows, then I'm sure I'm on to something.

    Per the handbook (and suggestion from George), I played noise through each the left and right speakers and when I move the balance all the way left, the stereo drivers play while only the dimensional drivers play on the right speaker. And vice versa.

    On to a parts list for the crossovers...would anyone make a suggestion of a shopping list? I am after best value. Not the cheapest, but nothing more than will satisfy most. At least the performance of stock.
    SDASRS2.3, SDA1C, Monitor 10, Monitor 7b
    Klipschorns, LaScalas, Heresy
    JBL8330a
    Infinity Kappa6
    Danley DTS10
    · Share on FacebookShare on Twitter
  • VR3
    VR3 Posts: 28,610
    My guess is you have a bad cap and possibly an inductor which does happen
    - Not Tom ::::::: Any system can play Diana Krall. Only the best can play Limp Bizkit.
    · Share on FacebookShare on Twitter
  • F1nut
    F1nut Posts: 50,494
    Like I originally stated, they are playing, but roughly 50% of the excursion and volume of the others.
    That is how they are supposed to be. The donut restricts the cone movement and therefore the volume level.
    Political Correctness'.........defined

    "A doctrine fostered by a delusional, illogical minority and rabidly promoted by an unscrupulous mainstream media, which holds forth the proposition that it is entirely possible to pick up a t-u-r-d by the clean end."

    President of Club Polk

    · Share on FacebookShare on Twitter
  • Viking64
    Viking64 Posts: 7,043
    edited July 11
    VR3 wrote: »
    a bad cap

    · Share on FacebookShare on Twitter
  • halo71
    halo71 Posts: 4,602
    tragusa3 wrote: »
    halo71 wrote: »
    Tony, aren't you glad I told you about those 2.3's in Dawsonville? lol

    Gary, are you being sarcastic? I knew what I might be getting into, and I certainly stepped into a project. I'm thankful for you, but not glad yet. It's all part of the journey. :smile:

    Yes, just messing with you Tony.
    --Gary--
    Onkyo Integra M504, Bottlehead Foreplay III, Denon SACD, Thiel CS2.3, NHT VT-2, VT-3 and Evolution T6, Infinity RSIIIa, SDA1C and a few dozen other speakers around the house I change in and out.
    · Share on FacebookShare on Twitter
  • skipshot12
    skipshot12 Posts: 1,157
    If you want cheaper side go back with stock caps but, since you’re in there go with film caps and upgrade your resistors too.

    Sonicaps & vishays….

    Make sure your inductors are good.
    · Share on FacebookShare on Twitter
  • xschop
    xschop Posts: 5,000
    edited July 11
    Clarity caps and you'll have money left for beer. But you were still wired wrong as @Gardenstater pointed out, and Sonicaps won't help that.
    Don't take experimental gene therapies from known eugenicists.
    · Share on FacebookShare on Twitter
  • skipshot12
    skipshot12 Posts: 1,157
    Great job.
    Now crack a frosty beverage & enjoy those speakers…..
    · Share on FacebookShare on Twitter
  • skipshot12
    skipshot12 Posts: 1,157
    Any way you can share the sound with a video?
    · Share on FacebookShare on Twitter
  • tragusa3
    tragusa3 Posts: 48
    skipshot12 wrote: »
    Any way you can share the sound with a video?

    I tried to post a video and it seems to only allow pictures? I'll look again.
    SDASRS2.3, SDA1C, Monitor 10, Monitor 7b
    Klipschorns, LaScalas, Heresy
    JBL8330a
    Infinity Kappa6
    Danley DTS10
    · Share on FacebookShare on Twitter
  • JCL
    JCL Posts: 145
    Glad you got it worked out! That makes sense if everything at the binding posts measured correctly.
    L600 (front), R200 (rear), R200 (rear surround), L400 (center), Sunfire HRS-10 (2)Marantz AV7706Sunfire Cinema Grand, Marantz M8077, Music Hall Stealth, Ortofon bronze cartridge, Parasound Zphono XRM, Sony UBP-X800
    · Share on FacebookShare on Twitter
  • skipshot12
    skipshot12 Posts: 1,157
    edited July 11
    Would like to hear your results please.

    I have trouble posting videos too.
    Someone told me to do it as a YouTube video then paste the link.
    That works well but is pain in the butt for me being digitally challenged.
    · Share on FacebookShare on Twitter
  • SCompRacer
    SCompRacer Posts: 8,491
    Glad you got it fixed! Nice work Trey!

    We have a clock similar to yours.




    Salk SoundScape 8's * Audio Research Reference 3 * Bottlehead Eros Phono * Park's Audio Budgie SUT * Krell KSA-250 * Harmonic Technology Pro 9+ * Signature Series Sonore Music Server w/Deux PS * Roon * Gustard R26 DAC / Singxer SU-6 DDC * Heavy Plinth Lenco L75 Idler Drive * AA MG-1 Linear Air Bearing Arm * AT33PTG/II & Denon 103R * Richard Gray 600S * NHT B-12d subs * GIK Acoustic Treatments * Sennheiser HD650 *
    · Share on FacebookShare on Twitter
  • SCompRacer
    SCompRacer Posts: 8,491
    edited July 11
    skipshot12 wrote: »
    Someone told me to do it as a YouTube video then paste the link.
    That works well but is pain in the butt for me being digitally challenged.

    Yup, that's what you have to do. This applies to Trey. :)

    https://youtu.be/Ru-8Pfrosp4?si=NvWkzTjGMHuiSZj-

    Salk SoundScape 8's * Audio Research Reference 3 * Bottlehead Eros Phono * Park's Audio Budgie SUT * Krell KSA-250 * Harmonic Technology Pro 9+ * Signature Series Sonore Music Server w/Deux PS * Roon * Gustard R26 DAC / Singxer SU-6 DDC * Heavy Plinth Lenco L75 Idler Drive * AA MG-1 Linear Air Bearing Arm * AT33PTG/II & Denon 103R * Richard Gray 600S * NHT B-12d subs * GIK Acoustic Treatments * Sennheiser HD650 *
    · Share on FacebookShare on Twitter
  • Viking64
    Viking64 Posts: 7,043
    SCompRacer wrote: »
    Glad you got it fixed! Nice work Trey!

    We have a clock similar to yours.
    My mother had a picture of that same exact mill from almost exactly that same angle.
    · Share on FacebookShare on Twitter
  • SCompRacer
    SCompRacer Posts: 8,491
    edited July 11
    Viking64 wrote: »
    My mother had a picture of that same exact mill from almost exactly that same angle.

    I got it from a polk forum member, a photographer. He had it listed on facebook IIRC. My account is gone so can't recall his name or screen name. IIRC he was a fireman at one time?
