Must try MOD - Foam inside the stamped steel baskets - YES!

Gardenstater
Gardenstater Posts: 3,301
edited December 2021 in Vintage Speakers
I previously mentioned this in a couple of scattered places and didn't open up a dedicated thread. I suppose I didn't want to stick my neck out until there was confirmation from another who has tried it ✔. I've been living with this for almost 6 mos. now and I still continue to be super pleased with the benefits (I think the foam is still breaking in...kidding)! I used Armacell closed cell 1/8" thick foam but this is open to experimentation with perhaps open cell, composite of open cell over closed, felt over closed, felt alone......just keep it relatively thin like maybe 1/4" max(?). Let's get some more people trying this because it is a super rewarding mod and not all that difficult to do.

I won't get super long winded but I posted my initial report over in the other thread "What did you do to your stereo today" on p. 122.

https://forum.polkaudio.com/discussion/184609/what-did-you-do-to-your-stereo-rig-today/p122

Pictures are always worth more than words. I think the benefit of this is 3 fold: 1) Mechanical vibration dampening of the basket, 2) Sound proofing of the basket preventing acoustical into mechanical excitation, and 3) some amount of reflection attenuation of backwave reflections that would come back and hit the back of the cone. 3) is last but not least because when I did just one speaker initially I had to rebalance with whitenoise by lowering the unmodded speaker's channel by 0.4dB to compensate. I believe that is due to the reduction in reflected backwave which comes out as audible sPL through the cone. That has to be distorted due to time delays and phase differences and varying transmission/reflection for different frequencies.

Anyway, Merry Christmas and let's have fun with this mod. I'll add pictures when I find them.

Initial sizing on a spare driver I had. Settled on 1-1/4" x 1-5/16" but not super critical as long as you don't block the basket windows. You can even trim the windows with an Xacto knife after install:




Completed driver with the Armacell inside of the spokes and the section between spokes near the spider. I cut off the 3 vestigial tabs with a dremel cut off wheel - be careful not to get metal dust inside the driver:
